LUXEON Integrated Modules speed the development of new luminaire solutions. Designed and manufactured by Lumileds, each integrated module incorporates LUXEON LEDs, selected at the factory, for performance, output, efficacy, color, and more to ensure consistent performance from board to board and luminaire to luminaire. Engineers no longer need to calculate for binning, voltage variances, and other LED differences – now they can design worry-free.

LUXEON XR-5050 HE

LUXEON XR-5050 HE products are standard integrated modules compatible with off-the-shelf drivers, optics and heat sinks. They are constructed with MCPCB substrates for thermal efficiency and mechanical robustness and eliminate engineering design costs, tooling costs, and material inventory costs. This versatile building-block approach simplifies system integration and accelerates time-to-market.

  • Efficacy and luminous flux of up to 184lm/W typical and 8600lm of output
  • Superior board level color control of ≤ 3SDCM
  • MCPCB for efficient heat dissipation and mechanical robustness
  • UL 8750, ENEC, CE, UKCA compliance
  • 5-year limited guarantee

LUXEON XR-5050 Round

LUXEON XR-5050Round products are LED modules optimized for lighting applications requiring high-efficacy LED arrays mounted on a rigid and thermally conductive substrate. These versatile building blocks feature 8, 12, or 16 LUXEON 5050 Square LEDs on a MCPCB substrate, electrical connectors, and are designed for ease of system integration, faster time to market, and use with industry-standard optics. LUXEON XR-5050 Round is a complete solution when used in combination with standard third-party optics and heatsinks.

  • Efficacy and luminous flux of up to 184lm/W and 5700lm of output
  • Superior board-level color control of ≤ 3SDCM
  • Compatible with standard third-party optics
  • Features LUXEON 5050 Round LEDs with industry-leading efficacy and lumens in multi-die, high-power package
  • 5-year guarantee

LUXEON XR-5050 SQR

LUXEON XR-5050 SQR products are LED modules optimized for lighting applications requiring high efficacy LED arrays mounted on a rigid and thermally conductive substrate. These versatile building blocks feature 8, 12 or 16 LUXEON 5050 Square LEDs on a MCPCB substrate, electrical connectors, and are designed for ease of system integration, faster time to market, and use with industry standard optics. LUXEON XR-5050 SQR is a complete solution when used in combination with standard third party optics and heatsinks.

  • Efficacy and luminous flux of up to 180lm/W and 5600lm of output
  • Superior board level color control of ≤ 3SDCM
  • Excellent case to heatsink thermal resistance of 3.5K/Wth
  • Design compatible with standard third party optics
  • Features LUXEON 5050 Square LEDs with industry-leading efficacy and lumens in multi-die, high power package
  • 5-year guarantee

LUXEON XR-7070

LUXEON XR-7070 product is a standard integrated module compatible with off-the-shelf drivers, optics, and heat sinks. Four LUXEON 7070 LEDs are built on a MCPCB substrate for thermal efficiency and mechanical robustness. Using this standard module eliminates LED-assembly engineering costs, tooling costs, and material inventory costs. With this versatile building-block approach, it simplifies system integration and accelerates time-to-market.

  • Efficacy and luminous flux of up to 170lm/W typical and 5400lm of output
  • CCT/CRI Options: 2700K, 3000K, 3500K, 4000K, 5000K (70 & 80 CRI)
  • Superior board-level color control of ≤ 3SDCM
  • MCPCB for efficient heat dissipation and mechanical robustness
  • Conformal coating option available
  • UL 8750, ENEC, CE, UKCA compliance
  • 5-year limited guarantee

LUXEON XR-HL2X

LUXEON XR-HL2X is a standard integrated module compatible with off-the-shelf drivers, optics, and heat sinks. These versatile building blocks feature 8, 12, or 16 LUXEON HL2X LEDs on a MCPCB substrate for thermal efficiency and mechanical robustness. This approach simplifies system integration and accelerates time-to-market.

  • Efficacy and Luminous flux of up to 184lm/W typ and 2800lm available
  • CCT/CRI Options:3000K, 4000K (70 CRI)
  • Board level color control of ≤ 5SDCM
  • MCPCB for efficient heat dissipation and mechanical robustness
  • UL 8750, ENEC, CE, UKCA compliance
  • 5-year limited guarantee
