LUXEON 2835 with CrispColor Technology

LUXEON 2835 with CrispColor Technology is the ultimate solution that makes fabrics come to life. With efficient solid state lighting technology, the contrast of colors has never been so vivid. Our special phosphor technology has created a higher gamut color rendering than existing solutions with a specific color point below the Black Body Line to allow for Class A products. Combined with industry leading performance in a common 2835 platform, LUXEON 2835 with CrispColor Technology creates a highly impactful retail experience with all of the advantages of LUXEON 2835, including leading performance, lower voltage, higher driving current, and excellent reliability.

LUXEON 2835 with CrispColor Technology product performance at 120mA, Tj=25°C.
PartVoltageNominal CCTMinimum CRILuminous
Flux (lm)
Typical Luminous Efficacy (lm/W)Part Number
MinimumTypical
2835 C3V2700K903642117L128-27HGCA3500000
3000K903843120L128-30HGCA3500000
3250K904045125L128-33HGCA3500000
3500K904046128L128-35HGCA3500000
4000K904247131L128-40HGCA3500000
5000K904450139L128-50HGCA3500000

Documentation

Design Resources

Features & Benefits

  • Industry standard footprint for drop-in replacement designs
  • Maximum drive current of up to 240mA allows for reduction of LED count
  • 3- and 5-step MacAdam ellipse color kits available

Applications
