Nov 2, 2022

LUXEON XR-HL2X and XR-5050 HE Standard Modules Provide a Faster Path to Lighting Solutions

San Jose, CA – November 02, 2022 – Utilizing two of Lumileds most popular and powerful LEDs, the company has released two new standard integrated modules, LUXEON XR-HL2X and LUXEON XR-5050 HE. Both offer lighting engineers a faster, simpler way to realize powerful, highly efficient lighting solutions. Standard optics are available for all the new boards, and both offer typical efficacy of 184 lumens per Watt.

With light output exceeding 8600 lumens at 184 lumens per Watt, ≤ 3SDCM color control, and 70, 80, and 90CRI options across the CCT range, LUXEON XR-5050 HE is a highly efficient solution. Both indoor and outdoor lighting, such as architectural, historical, high bay, pedestrian and roadway and sports lighting, can be realized more quickly and efficiently with the new LED boards from Lumileds.

“The energy crisis is top of mind for all and every advance is important. LUXEON XR 5050 HE delivers the efficacy in a robust format with proven LUXEON 5050 HE LEDs in a format that speeds time to market,” said Benjamin Khoo, Product Manager. “With immediate availability of standard optics and drivers, this is perhaps the most efficient and appropriate solution for high output energy saving fixtures.”

For typical light output levels ranging from 1400 to 2800 lumens, in 3000 and 4000K, 70CRI, with board level color control ≤ 5 SDCM, the LUXEON XR-HL2X is an excellent selection. The standard 8-up, 12-up, and 16-up boards use the Zhaga footprint and are compatible with off-the-shelf drivers, optics, and heat sinks. For many low bay and outdoor area lighting solutions, LUXEON XR-HL2X is exactly what is needed and eliminates the need to design and test boards and configurations.

Both of the new standard solutions use factory selected LEDs for color and performance consistency mounted on an MCPCB substrate that provides thermal efficiency and mechanical robustness. Both have UL8750, ENEC, CE, and UKCA approbations.

Complete product information and datasheets for LUXEON XR-5050 HE and LUXEON XR-HL2X LED can be found at


For further information, please contact:
Steve Landau
Director Marketing Communications

About Lumileds:

Lumileds is a global leader in OEM and aftermarket automotive lighting and accessories, camera flash for mobile devices, MicroLED, and light sources for general illumination, horticulture, and human-centric lighting. Our approximately 6,000 employees operate in over 30 countries and partner with our customers to deliver never before possible solutions for lighting, safety, and well-being. To learn more about our company and solution portfolios, please visit
