LUXEON 3030 HE and 3030 HE Plus

2023 Build Back Better Platinum Winner

Now with Platinum Award Winning NightScape Technology: Broadband white light with less than 2% blue content for better outdoor illumination.

The Build Back Better Awards champion innovation, creativity, environmental leadership, and social purpose in buildings. The Build Back Better Awards celebrate and reward the technologies and initiatives that will help us shape projects that point the way to a better future.

LUXEON 3030 HE and LUXEON 3030 HE Plus are superior high efficacy, mid-power packages built on the legacy of the LUXEON 3030 product line. It serves as a go-to solution for various indoor and outdoor fixture applications that require top-notch lm/W and umol/J performance and long lifetime. LUXEON 3030 HE and LUXEON 3030 HE Plus adopt quadrant bin structure within 3 SDCM, which enables 2 SDCM by kitting.

Features & Benefits

  • Broadband white light with <2%blue content – NightScape Technology
  • Superior high efficacy at rated current enables outstanding lm/W at the system level
  • Reliable package design from a proven product line affirms long application lifetime
  • Quadrant bin structure within 3 SDCM enables 2 SDCM by kitting
  • Industry-standard package allows drop-in replacement for existing 3030 packages
  • Robust coating design for enhanced sulfur protection capability (LUXEON 3030 HE Plus)
Expand Media

Applications

Expand Applications

Please read these terms and conditions carefully.

LUMILEDS shall not be liable for any kind of loss of data or any other damages, direct, indirect or consequential, resulting from the use of the provided information and data. Although LUMILEDS has attempted to provide the most accurate information and data, the materials and services information and data are provided “as is” and LUMILEDS neither warranties, nor guarantees the contents and correctness of the provided information and data. LUMILEDS reserves the right to make changes without notice. You as user agree to this disclaimer and user agreement with the download or use of the provided materials, information and data.

I agree I do not agree

Product performance of LUXEON 3030 HE and LUXEON 3030 HE Plus at 65mA, Tj= 25°C.

Product Nominal
CCT
Minimum
CRI
Luminous Flux (lm) Typical Luminous
Efficacy (lm/W)
Part Numbers
Minimum Typical
65mA
3030 HE 3000K 70 32.7 35.5 195 L130-3070HB30000B1
3500K 70 34.0 37.0 203 L130-3570HB30000B1
4000K 70 34.5 37.5 206 L130-4070HB30000B1
5000K 70 34.5 37.5 206 L130-5070HB30000B1
5700K 70 34.0 37.0 203 L130-5770HB30000B1
6500K 70 33.5 36.4 200 L130-6570HB30000B1
2700K 80 29.0 33.5 184 L130-2780HB30000B1
3000K 80 29.5 34.0 187 L130-3080HB30000B1
3500K 80 30.0 35.0 192 L130-3580HB30000B1
4000K 80 32.0 36.5 201 L130-4080HB30000B1
5000K 80 31.5 36.0 198 L130-5080HB30000B1
5700K 80 31.5 36.0 198 L130-5780HB30000B1
6500K 80 31.0 35.5 195 L130-6580HB30000B1
2700K 90 24.5 28.0 154 L130-2790HB30000B1
3000K 90 25.0 28.5 157 L130-3090HB30000B1
3500K 90 26.0 29.5 162 L130-3590HB30000B1
4000K 90 27.5 30.5 168 L130-4090HB30000B1
5000K 90 27.0 30.0 165 L130-5090HB30000B1
5700K 90 27.0 30.0 165 L130-5790HB30000B1
6500K 90 27.0 30.0 165 L130-6590HB30000B1
3030 HE Plus 1850K 50 29.5 32.2 183 L130-NSC1HA30000C1
2200K 70 29.5 32.0 182 L130-2270HA30000B1
3000K 70 34.0 37.0 210 L130-3070HA30000B1
3500K 70 35.0 38.0 216 L130-3570HA30000B1
4000K 70 36.0 39.0 221 L130-4070HA30000B1
5000K 70 36.0 39.0 221 L130-5070HA30000B1
5700K 70 35.0 38.0 216 L130-5770HA30000B1
6500K 70 34.5 37.5 213 L130-6570HA30000B1
2700K 80 30.0 33.5 190 L130-2780HA30000B1
3000K 80 32.0 35.0 199 L130-3080HA30000B1
3500K 80 33.0 36.0 204 L130-3580HA30000B1
4000K 80 34.0 37.0 210 L130-4080HA30000B1
5000K 80 34.0 37.0 210 L130-5080HA30000B1
5700K 80 33.5 36.5 207 L130-5780HA30000B1
6500K 80 33.0 36.0 204 L130-6580HA30000B1
2700K 90 26.0 28.5 162 L130-2790HA30000B1
3000K 90 27.0 29.5 167 L130-3090HA30000B1
3500K 90 27.5 30.5 173 L130-3590HA30000B1
4000K 90 28.5 31.5 179 L130-4090HA30000B1
5000K 90 28.5 31.5 179 L130-5090HA30000B1
5700K 90 28.5 31.5 179 L130-5790HA30000B1
6500K 90 28.0 31.0 176 L130-6590HA30000B1
2200K 70 29.5 33.1 188 L130-2270HA30000C1
3000K 70 34.0 37.7 215 L130-3070HA30000C1
3500K 70 35.0 38.7 221 L130-3570HA30000C1
4000K 70 36.0 39.4 224 L130-4070HA30000C1
5000K 70 36.0 39.4 224 L130-5070HA30000C1
5700K 70 35.0 38.4 219 L130-5770HA30000C1
6500K 70 34.5 38.0 216 L130-6570HA30000C1
2700K 80 30.0 33.8 193 L130-2780HA30000C1
3000K 80 32.0 35.2 201 L130-3080HA30000C1
3500K 80 33.0 36.5 208 L130-3580HA30000C1
4000K 80 34.0 37.6 214 L130-4080HA30000C1
5000K 80 34.0 37.6 214 L130-5080HA30000C1
5700K 80 33.5 37.0 211 L130-5780HA30000C1
6500K 80 33.0 36.6 209 L130-6580HA30000C1
2700K 90 26.0 28.7 163 L130-2790HA30000C1
3000K 90 27.0 30.1 171 L130-3090HA30000C1
3500K 90 27.5 30.4 173 L130-3590HA30000C1
4000K 90 28.5 31.6 180 L130-4090HA30000C1
5000K 90 28.5 32.3 184 L130-5090HA30000C1
5700K 90 28.5 32.2 184 L130-5790HA30000C1
6500K 90 28.0 31.3 178 L130-6590HA30000C1
