Features & Benefits

ANSI and general purpose binning.%Complete CCT range including LEDs binned to the ANSI standard.Exceeds ENERGY STAR® lumen maintenance requirements.%Superior color rendering.%Industry leading thermal characteristics.%Very small optical source size.%Lead and mercury free, RoHS and REACH Compliant.%Electrically isolated thermal pad simplifies PC board design.%JEDEC Class 1 moisture sensitivity level.%Lead-free reflow solder JEDEC 020c compatible.%Complete design resources including electrical, me
